Verify the pinout and maximum ratings in the manufacturer datasheet.
Pinout / Lead Arrangement
1 Collector
2 Base
3 Emitter
TO-92 front view
TO-92 bottom view
ⓘ Note:With the flat face toward you, the leads follow the front-view order shown above. Turning the component over reverses left and right. Verify the pinout in the manufacturer datasheet before connecting it.
1CollectorC2BaseB3EmitterE
Always verify the lead arrangement in the package-specific datasheet before connecting the component.
